-SCADA

- Product Operation
Smart Tracking Algorithm (STA)
· The bifacial irradiation model comprehensively considers 12 key factors affecting power generation.
· Multi-dimensional analysis of module power generation performance to ensure optimal power generation throughout the entire cycle.
· Reduce bracket rotation and effectively extend the service life of the motor and bracket.

Smart Backtracking Algorithm (SBA)
· Multiple technologies intelligently identify real terrain
· Automated training and learning, no human participation required
· Secondary precise optimization of backtracking angle based on the power generation characteristics of module shading.

- Power Generation Efficiency And Project Cases

- Pile Foundation Form

- Packing & Transportation



-SCADA

- Product Operation
Smart Tracking Algorithm (STA)
· The bifacial irradiation model comprehensively considers 12 key factors affecting power generation.
· Multi-dimensional analysis of module power generation performance to ensure optimal power generation throughout the entire cycle.
· Reduce bracket rotation and effectively extend the service life of the motor and bracket.

Smart Backtracking Algorithm (SBA)
· Multiple technologies intelligently identify real terrain
· Automated training and learning, no human participation required
· Secondary precise optimization of backtracking angle based on the power generation characteristics of module shading.

- Power Generation Efficiency And Project Cases

- Pile Foundation Form

- Packing & Transportation


Main Material
ZAM(S440~S550)/Q355B/Q235B
Fastener Material
304 (A2-70) Flange Bolt + Flange Nut
Azimuth Tracking Range (°)
-50°~+50°/-60°~+60°(Customizable)
Survival Wind Speed
37~60 m/s (ASCE7-10, Can be Customized)
Control Algorithm
Astronomical Algorithm + Position Sensor Closed Loop Control
( + Multi-Drive Synchronous Operation Control)
String DC250~1500V power supply
Local Network Communication
Remote Network Communication
Optional Wired: RS485/0ptical fiber/Power line carrier
Backtracking Algorithm
Have (Al algorithm can be upgraded)
SCADA
Have (Functions and interface can be customized)
Position Protection Mode
Sensor Protection + Software Protection
System Upgrade
Remote One-Click Upgrade + Local Upgrade
Operating Temperature(C)
Default On -30℃~+70℃(Customizable)
Compatible with:2279mmx1134mm(144) / 2384mm*1134mm(132)
{"json":"[{\"index\":\"0\",\"tran_value\":[\"≈ 341 ㎡(317㎡/331㎡)\"],\"tran_label\":\"Grid Area\"},{\"index\":\"1\",\"tran_value\":[\"2456mmx 1134mm(156)\"],\"tran_label\":\"Size of Solar Panel\"},{\"index\":\"3\",\"tran_label\":\"Main Material\",\"tran_value\":[\"ZAM(S440~S550)/Q355B/Q235B\"]},{\"index\":\"4\",\"tran_label\":\"Fastener Material\",\"tran_value\":[\"304 (A2-70) Flange Bolt + Flange Nut\"]},{\"index\":\"5\",\"tran_label\":\"North-South Slope\",\"tran_value\":[\"<20%\"]},{\"index\":\"6\",\"tran_label\":\"Azimuth Tracking Range (°)\",\"tran_value\":[\"-50°~+50°/-60°~+60°(Customizable)\"]},{\"index\":\"7\",\"tran_label\":\"Snow Load\",\"tran_value\":[\"0.8~1.1 KN/m\"]},{\"index\":\"8\",\"tran_label\":\"Protection Wind Speed\",\"tran_value\":[\"Have(17~22 m/s)\"]},{\"index\":\"9\",\"tran_label\":\"Survival Wind Speed\",\"tran_value\":[\"37~60 m/s (ASCE7-10, Can be Customized)\"]},{\"index\":\"10\",\"tran_label\":\"Control Algorithm\",\"tran_value\":[\"Astronomical Algorithm + Position Sensor Closed Loop Control\"]},{\"index\":\"11\",\"tran_label\":\"\",\"tran_value\":[\"( + Multi-Drive Synchronous Operation Control)\"]},{\"index\":\"12\",\"tran_label\":\"Protection Level\",\"tran_value\":[\"IP65\"]},{\"index\":\"13\",\"tran_label\":\"Power Supply Mode\",\"tran_value\":[\"AC100~305V power supply\"]},{\"index\":\"14\",\"tran_label\":\"\",\"tran_value\":[\"String DC250~1500V power supply\"]},{\"index\":\"15\",\"tran_label\":\"Local Network Communication\",\"tran_value\":[\"LoRa /Zigbee\"]},{\"index\":\"16\",\"tran_label\":\"Remote Network Communication\",\"tran_value\":[\"Optional Wired: RS485/0ptical fiber/Power line carrier\"]},{\"index\":\"17\",\"tran_label\":\"\",\"tran_value\":[\"Wireless: 4G/WiFi\"]},{\"index\":\"18\",\"tran_label\":\"Night Return Mode\",\"tran_value\":[\"Have\"]},{\"index\":\"19\",\"tran_label\":\"Cloudy Mode\",\"tran_value\":[\"Optional\"]},{\"index\":\"20\",\"tran_label\":\"Backtracking Algorithm\",\"tran_value\":[\"Have (Al algorithm can be upgraded)\"]},{\"index\":\"21\",\"tran_label\":\"Heavy Rain Cleaning Mode\",\"tran_value\":[\"Optional\"]},{\"index\":\"22\",\"tran_label\":\"SCADA\",\"tran_value\":[\"Have (Functions and interface can be customized)\"]},{\"index\":\"23\",\"tran_label\":\"Position Protection Mode\",\"tran_value\":[\"Sensor Protection + Software Protection\"]},{\"index\":\"24\",\"tran_label\":\"Snow Removal Mode\",\"tran_value\":[\"Optional\"]},{\"index\":\"25\",\"tran_label\":\"Cleaning Robot\",\"tran_value\":[\"Customizable\"]},{\"index\":\"26\",\"tran_label\":\"System Upgrade\",\"tran_value\":[\"Remote One-Click Upgrade + Local Upgrade\"]},{\"index\":\"27\",\"tran_label\":\"NCU Visual Operation\",\"tran_value\":[\"Have\"]},{\"index\":\"28\",\"tran_label\":\"Tracking Cycle\",\"tran_value\":[\"Can be Set Up\"]},{\"index\":\"29\",\"tran_label\":\"Operating Temperature(C)\",\"tran_value\":[\"Default On -30℃~+70℃(Customizable)\"]},{\"index\":\"30\",\"tran_value\":[\"Compatible with:2279mmx1134mm(144) / 2384mm*1134mm(132)\"]}]","type":"2"}
